OHAUS Explorer Plus Precision EXP Balance
The OHAUS Explorer Plus Precision EXP Balance is engineered for the lab professional who requires exceptional repeatability, efficient workflows and effortless connectivity. With capacities ranging into the kilograms and readability down to 0.01 g (depending on model), this precision balance pairs a large 7-inch color touchscreen interface with next-generation automation and network integration to streamline your operations. From parts counting and formulation to density measurement and flow-rate control, the EXP Precision supports the wide range of tasks your lab demands. Designed for demanding applications, it also gives you robust traceability features, advanced data handling, and a build quality that handles real-world lab environments.
Key Features
- Touch-screen display: 7″ TFT glass-overlay, full-color, intuitive user interface
- Motorized self-leveling: Automatic leveling mechanism simplifies setup and ensures accuracy
- Hands-free operation: Touchless sensors for doors or draft-shield operation reduce disturbance and increase efficiency
- Safety-focused design: Anti-pinch automatic doors, anti-static glass draft-shield (on selected models) for safe, consistent weighing
- Broad connectivity and data handling: USB-A, USB-B, USB-C, RS-232, Ethernet ports, and optional WiFi/Bluetooth modules support integration into LIMS/MES systems
| Specifications for EXPLORER PLUS Precision Balances | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8245-12 | 8245-11 | 8245-14 | 8245-03 | 8245-10 | 8245-15 | 8245-02 | 8245-09 | 8245-01 | 8245-13 | 8245-04 | 8245-16 | |
| Model | EXP223/AD | EXP423/AD | EXP623/AD | EXP1203/AD | EXP2202 | EXP4202 | EXP6201 | EXP6202 | EXP8201 | EXP8202 | EXP10201 | EXP12202 |
| Maximum Capacity | 220.0 g | 420.0 g | 620.0 g | 1200.0 g | 2200.0 g | 4200.0 g | 6200.0 g | 6200.0 g | 8200.0 g | 8200.0 g | 10200.0 g | 12200.0 g |
| Readability | 1 mg | 0.01 g | 0.1 g | 0.01 g | 0.1 g | 0.01 g | 0.1 g | 0.01 g | ||||
| Pan Size | 5.1 in x 5.1 in (130 mm x 130 mm) | 7.9 in x 7 in (201 mm x 178 mm) | ||||||||||
| Internal Calibration | AutoCal™ - Automatic | |||||||||||
| Draftshield | Included | — | ||||||||||
| Dimensions LxHxW | 16.1 in x 14.6 in x 9 in | 16.1 in x 3.8 in x 9 in | ||||||||||
| Battery Life | Not Applicable | |||||||||||
| Legal for Trade | Not Applicable | |||||||||||
| Auto Door | Anti-pinch autodoors | Not Applicable | ||||||||||
| Tare Range | To capacity by subtraction | |||||||||||
| Working Environment | 10°C – 30°C, 80%RH, non-condensing | |||||||||||
| Net Weight | 17.2 lb (7.8 kg) | 12.1 lb (5.5 kg) | ||||||||||
| In-Use Cover | Included | |||||||||||
| Communication | USB device; USB host x 2; RS232; Ethernet TCP/IP;WiFi/Bluetooth (available as an accessory) | |||||||||||
| Power | AC Adapter (Included) | |||||||||||
| Units of Measurement | Singapore Tael; Ounce Troy; Pennyweight; Grain; Tical; Custom; Milligram; Momme; Newton; Baht; Taiwan Tael; Gram; Hong Kong Tael; Tola; Mesghal; Carat; Ounce |
|||||||||||
| Minimum Weight | 0.14 g | 1.4 g | 14 g | 1.4 g | 14 g | 1.4 g | 14 g | 1.4 g | ||||
| Display | 7" colour TFT touchscreen | |||||||||||
| Pan Construction | Stainless Steel | |||||||||||
| Built-in Ionizer | Yes | No | ||||||||||
| Stabilization Time | 1.5 s | 1 s | ||||||||||
| Repeatability, typical | 1 mg | 0.01 g | 0.1 g | 0.01 g | 0.1 g | 0.01 g | 0.1 g | 0.01 g | ||||
| Minimum Weight (USP, 0.1%, typical) |
1.4 g | 14 g | 140 g | 14 g | 140 g | 14 g | 140 g | 14 g | ||||
| Linearity ± | 2 mg | 0.02 g | 0.2 g | 0.02 g | 0.2 g | 0.02 g | 0.2 g | 0.02 g | ||||
| Item No. | Capacity | Calibration | Model | Pan Size | Readability | Unit of Measure | Your Cost | Purchase |
|---|---|---|---|---|---|---|---|---|
|
PRECISION BALANCE EXP223/AD
8245-01
|
220.0 g | AutoCal™ - Automatic | EXP223/AD | 5.1 x 5.1 in | 1mg | Each |
$3,742.55
|
|
|
PRECISION BALANCE EXP12202
8245-13
|
12200.0 g | AutoCal™ - Automatic | EXP12202 | 7.0 x 7.9 in | 0.01g | Each |
$6,089.40
|
|
|
PRECISION BALANCE EXP10201
8245-16
|
10200.0 g | AutoCal™ - Automatic | EXP10201 | 7.0 x 7.9 in | 0.1 g | Each |
$4,676.70
|
|
|
PRECISION BALANCE EXP623/AD
8245-03
|
620.0 g | AutoCal™ - Automatic | EXP623/AD | 5.1 x 5.1 in | 1mg | Each |
$5,347.35
|
|
|
PRECISION BALANCE EXP4202
8245-10
|
4200.0 g | AutoCal™ - Automatic | EXP4202 | 7.0 x 7.9 in | 0.01g | Each |
$4,523.70
|
|
|
PRECISION BALANCE EXP423/AD
8245-02
|
420.0 g | AutoCal™ - Automatic | EXP423/AD | 5.1 x 5.1 in | 1mg | Each |
$4,376.65
|
|
|
PRECISION BALANCE EXP6201
8245-14
|
6200.0 g | AutoCal™ - Automatic | EXP6201 | 7.0 x 7.9 in | 0.1 g | Each |
$4,269.55
|
|
|
PRECISION BALANCE EXP8202
8245-12
|
8200.0 g | AutoCal™ - Automatic | EXP8202 | 7.0 x 7.9 in | 0.01g | Each |
$5,609.15
|
|
|
PRECISION BALANCE EXP6202
8245-11
|
6200.0 g | AutoCal™ - Automatic | EXP6202 | 7.0 x 7.9 in | 0.01g | Each |
$5,134.00
|
|
|
PRECISION BALANCE EXP1203/AD
8245-04
|
1200.0 g | AutoCal™ - Automatic | EXP1203/AD | 5.1 x 5.1 in | 1mg | Each |
$6,267.90
|
|
|
PRECISION BALANCE EXP2202
8245-09
|
2200.0 g | AutoCal™ - Automatic | EXP2202 | 7.0 x 7.9 in | 0.01g | Each |
$3,935.50
|
|
|
PRECISION BALANCE EXP8201
8245-15
|
8200.0 g | AutoCal™ - Automatic | EXP8201 | 7.0 x 7.9 in | 0.1 g | Each |
$4,471.00
|
